GPL-2000WAC-KIT

Characteristics:

Wave 2 G.hn Powerline Adapter | Wireless AC 1200 | 2000Mbps

Description

Solve dead Wireless zones in hard-to-reach locations using the existing electrical wiring with GPL-2000WAC-KIT. The GPL-2000WAC has next-generation G.hn Wave 2 technology, allowing it to reach up to 2000Mbps PHY rates over the Powerline connection and up to 500Mbps through a single Ethernet port.

This GPL-2000WAC-KIT comes with one GPL-2000WAC adapter and one GPL-2000PT adapter.

SKU GPL-2000WAC-KIT Categories , Tags , , , ,

Product Description

Features

  • Delivers better real world performance than standard powerline technology.
  • Enhances performance and video streaming using LDPC/FEC (Forward Error Correction) technology.
  • Designed to work in high density environments (eg. Apartments, business offices, condos, hotels, etc.).
  • Supports an internationally recognized powerline standard (ITU-T) for true compatibility.
  • New Quick Noise Adaptation (QNA) technology for 5x faster noise detection.

Additional Information

Technology

G.hn Wave 2

Interface

GPL-2000PT: One RJ-45 for Ethernet Connection, LED Indicators, Power, G.hn, Security (PLC), LAN, Buttons: G.hn pairing, RESET, GPL-2000WAC: One RJ-45, LED Indicators: Power, Connection, Security, 2.4GHz, 5GHz, WPS, Ethernet, Buttons: G.hn Pairing, Reset, WPS, WiFi ON/OFF, Two Internal WiFi antenna X 2

Ethernet

GPL-2000PT: Standard IEEE 802.3u, 802.3ab, One 10/100/1000 BaseT Ethernet Port, Auto Rate and Duplex Negotiation, MDI/MDX Support, GPL-2000WAC: Standard IEEE 802.3, 10/100/1000 Mbps BaseT auto-sense, Auto rate and duplex negotiation MDI/MDX support

Modulations

FEC, Flexible Frequency Configuration, OFDM

Management

Firmware upgrade via TFTP, HTTP Web-based Management

Security

AES 128 Bits Encryption Ensures Total Data Security, Configuration Button for Factory Reset, One Button Security Set-up

Networking Protocols

802.1D Ethernet Bridge, 802.1Q VLAN, IGMP (IPv4) Snooping, MLD(IPv6) Snooping, Quality of Service (QoS)

Power

100-240 VAC 50Hz/60Hz

Environment Condition

Designed for Indoor Use Only, Operating temperature: 32~104F (0~40°C), Relative Humidity: 8~95% (non-condensing)

Dimension

GPL-2000PT: Dimensions (H)140mm x (W)70mm x (D)60/39mm (with/without plug), Dimensions (H)5.50in x (W)2.75in x (D)2.36in/1.54in (with/without plug), GPL-2000WAC: Dimensions (H)164.5mm x (W)86mm x (D)40.5 /57mm (with/without plug), Dimensions (H)6.47in x (W)3.39in x (D)1.59/2.24in (with/without plug)

Certification

FCC, HomeGrid Forum, ITU-T G.hn Standard


GHN_DataSheet.pdf


GPL-2000WAC-KIT_QIG.pdf
